STM32F103C6T6 Minimum System Board FLASH Microcontroller Development Board C6T6 Core Board

STM32F103C6T6 Minimum System Board FLASH Microcontroller Development Board C6T6 Core Board Kuvaus

1. This product is a 32-bit microcontroller based the Cortex-M3 kernel, providing high operating frequency and powerful performance.
2. The main frequency of the chip used is as high as 72MHz, and it has very rich -chip resources, which can fully meet the needs of STM32 learning.
3. The built-in flash memory integrates Flash memory for storing code and programs, with excellent performance, abundant resources, and ultra-high cost-effectiveness.
4. Multiple GPIOs with multiple universal input/output pins (GPIOs) for connecting external devices.
5. It has a wide range of applications, including but not limited to industrial automation, automotive electronics, household appliances, medical equipment, homes, and embedded systems.

Specification:B: STM32F103C6T6:
Main control chip: STM32F103C6T6
Input voltage: USB 5V
Output voltage: 3.3V/5V
3V3/5V maximum power supply current: 500MA
Timer: 3 (without timer 4)
Serial port: 2 (without serial port 3)
USB function: 1
[KB]:10KBytes
Flash[KB]:32KBytes
Download method: SWD, serial port download
Suggestion:
The Flash of the program is less than 32K, the RAM is less than 10K, and STM32F103C6T6 can be used instead of timer 4 and serial port 3, which has a price advantage.
Colour:Black
Material:PC

Package Contents:
1 x Development Board(Due to different product batches, the appearance may vary, which does not affect the use)
