2X EBYTE E220-900T22D LoRa LLCC68 Wireless Module 22dBm 5km SMA-K UART RSSI Transmitter Receiver DIP W/ 868MHz Antenna

New

8 482,22 Ft

További termékek, amelyek érdekelhetnek

Hálózati adó-vevőkészülékek

Would you like us to let you know when it's back?

Kosárba

Leírás és részletek

Összefoglaló

Use chips LLCC68. Compared with the SX1278/SX1276 solution, the transmission distance is longer,the speed is faster ,and the power consumption is lower.
Cost-effective LoRa wireless UART module.
Communication key. RSSI environmental monitoring.
Power failure protection.
Power multi-level adjustable.

2X EBYTE E220-900T22D LoRa LLCC68 Wireless Module 22dBm 5km SMA-K UART RSSI Transmitter Receiver DIP W/ 868MHz Antenna leírása

Use chips LLCC68. Compared with the SX1278/SX1276 solution, the transmission distance is longer,the speed is faster ,and the power consumption is lower.
Cost-effective LoRa wireless UART module.
Communication key. RSSI environmental monitoring.
Power failure protection.
Power multi-level adjustable.

Working Frequency band:850.125-930.125MHZ (Support ISM band)
Transmitting Power:22dBm
Air rate: 2.4k-62.5kbps (user-configured)
Reference distance: 5000m
Transmitting current: 110mA (instantaneous power consumption)
Receiving current: 16.8mA
Operating voltage: 3.0-5.5V (Greater than 5.0V can guarantee output power)
Operating temperature: -40C-+85C (industrial grade design)
Communication interface: UART serial port (TTL level)
Color: As Shown
Material: Plastic+Metal

Package Contents:
2 x E220-900T22D Module
2 x 868MHz Antenna
