3in1 Multi-Function Digital Oscilloscope Dual Channel 250MSa/S Sampling Rate 3.2inch IPS Display

3in1 Multi-Function Digital Oscilloscope Dual Channel 250MSa/S Sampling Rate 3.2inch IPS Display leírása

[3In1 Design with IPS Display]: This product ingeniously integrates digital oscilloscope, multimeter, and signal generator functions into one device. 3.2-inch clear-definition IPS display, high sensitivity full view display, channel 2 waveforms can be set to green/ cyan/.
[Signal Generator]: Built-in waveform signal generator, it can output sinewave, squarewave, trianglewave, and so . The voltage amplitude is 2.5V, the frequency is adjustable from 0-2Mhz, and the squarewave duty cycle is adjustable from 1% to 99%.
[High-precise Multimeter]: Built-in true RMS multimeter, that supports quick software calibration. With /ACvoltage, /ACcurrent, resistance, capacitance, diode, and continuity test.
[Wide Applications]: It can easily handle measurement in various fields, widely used in the fields of testing and debugging of electronic circuits, troubleshooting and repairing of elect

Name: 3in1 Digital Oscilloscope
Display: 3.2 inches IPS color screen
Charging: TYPE-C 5V
Language: Chinese/English
Oscilloscope:
Real- sample rate: 200Msps
Analog Bandwidth: 120MHz (CH1 only); 60MHz (CH1+CH2)
Equivalent sampling: 500M
Rise : Less than 3ns
Storage: 128Kb
Impedance: 1MΩ
Base: 5ns- 10s
Peakvoltage: 40V (1x), 400V (10x)
Trigger mode: auto/normal/single
Trigger type: rise/fall
Display mode: YT /XY/roll
Persistence: none/1s/
Auto mode: oneKey-auto/fully-auto
Sensitivity: X1:10mV/div-10V/div; X10:100mV/div-100V/div
Measure items: 14 types
Offset: 2%
XY mode: yes
Screenshot: yes
Frequency: 0.01%
mode: yes
FFT: yes
Generator waves: sin/square/triangular
Generator Vol: 2.5V0.05
Generator freq: 1Hz-2MHz
Colour:Photo Color
Material:ABS

Package Contents:
1 x 3 in 1 digital oscilloscope
1 x test pen
2 x cables
1 x accessories set(The color of accessor
