DOS LCD Oscilloscope Kit STC8K8A Single Chip Microcomputer Electronic Soldering Practice Loose Parts Without Shell

DOS LCD Oscilloscope Kit STC8K8A Single Chip Microcomputer Electronic Soldering Practice Loose Parts Without Shell leírása

This is a simple oscilloscope made with an STC8A8K microcontroller. It only requires a small amount of components and is easy to assemble.
The function can cover simple measurements.
This kit aims to build a basic oscilloscope model with the simplest possible principles and as little hardware as possible.
The source code is easy to understand, and it is also very suitable for interested electronic enthusiasts to learn and research while using the product.

Product name:-DSO microcontroller oscilloscope kit
Working voltage:4-5V
Single chip computer:STC8A8K64S4A12
Display:0.96 inch OLED display screen -7P, 128x64 resolution
Number of channels:single channel
Sec/div:500ms, 200ms, 100ms, 50ms, 20ms, 10ms, 5ms, 2ms, 1ms, 500us, 200us, 100us (100us only available in automatic trigger mode)
Voltage range:0-30V
Sampling level:10kHz@100us /Div
Trigger level:Trigger voltage level
Trigger slope: - rising , - falling trigger
Trigger mode:A-automatic mode, N-normal mode, S-single mode.
Note:Due to different production batches, the appearance is different, which does not affect the use.
Colour:
Material:PCB+electronic components
Size:PCB size:57x34mm

Package Contents:
1 * DOS LCD Oscilloscope DIY Kit
