For Heltec T114 V2 Tracker NRF52840 SX1262 LoRaWAN LoRa 1.14 Inch Display Devboard Low Power BLE Meshtastic with Battery

Opis produktu: For Heltec T114 V2 Tracker NRF52840 SX1262 LoRaWAN LoRa 1.14 Inch Display Devboard Low Power BLE Meshtastic with Battery

Mesh Node T114 is a development board based nRF52840 and SX1262, supports LoRa and 5.0.
It integrated a variety of power interfaces (5V USB, lithium battery and solar panel), with 1.14 inch TFT display and GPS module as accessories, and has powerful long-distance communication capabilities, scalability, and low power design.
Its six-layer PCB architecture and optimized RF circuit design make it especially suitable and durable for LoRa/LoRaWAN applications such as device tracking and remote monitoring systems.
The T114 enables development through environment like and PlatformIO, offering full compatibility with well-known open-source projects like Meshtastic and MeshCore.
Main Features:
MCU nRF52840 (), LoRa chipset SX1262.
Powerful display function, onboard 1.14 inch TFT-LCD display contains 135(H)RGBx240(V) dots and can display to 262k colors
Low power consumption, 11 uA in deep sleep
Powerful display function, onboard 1.9-inch TFT-LCD display contains 170 (RGB)X320 dots and can display to 262k colors.
Operation condition: -20 ~ 70, 90%RH(No condensing).
Type-C USB interface with a complete voltage regulator, ESD protection, short circuit protection, RF shielding, and other protection measures
Various Interfaces: 1.25*2P LiPo connector, 1.25*2P Solar panel connector, 1.25*8P GNSS module connector, which greatly increase the extensibility of the board.
Color: As Shown
Material: plastic

Package Contents:
1 * T114 V2 Tracker kit
