Rezumat
- 1. Analog voltage sensors: accelerator pedal sensor, throttle position sensor, oxygen sensor, fuel rail pressure sensor, for boost pressure sensor, oil pressure sensor, intake pressure sensor, air conditioning pressure sensor, etc.
- 2. Analog resistance sensors: coolant temperature sensor, intake temperature sensor, oil temperature sensor, exhaust temperature sensor, fuel temperature sensor, evaporator temperature sensor, ambient temperature sensor, etc.
- 3. Oxygen sensor signal 0.1-0.9V automatic jump. 4. The ratio of the two signals of the accelerator pedal sensor is 2:1. 5. The sum of the two signals of the throttle position sensor is 5V. 6. Built-in for multi-turn wirewound potentiometer.
- 7. Multiple sensor signals are output simultaneously, and each signal is adjusted independently without interfering with each other.
- Automotive Computer Diagnostics
Descriere MN300 Multi Channel Automotive Sensor Simulator for Testing Throttle Position Oxygen and Oil Pressure Sensor Effectively
1. Analog voltage sensors: accelerator pedal sensor, throttle position sensor, oxygen sensor, fuel rail pressure sensor, for boost pressure sensor, oil pressure sensor, intake pressure sensor, air conditioning pressure sensor, etc.
2. Analog resistance sensors: coolant temperature sensor, intake temperature sensor, oil temperature sensor, exhaust temperature sensor, fuel temperature sensor, evaporator temperature sensor, ambient temperature sensor, etc.
3. Oxygen sensor signal 0.1-0.9V automatic jump. 4. The ratio of the two signals of the accelerator pedal sensor is 2:1. 5. The sum of the two signals of the throttle position sensor is 5V. 6. Built-in for multi-turn wirewound potentiometer.
7. Multiple sensor signals are output simultaneously, and each signal is adjusted independently without interfering with each other.
Specifications:
Part name: MN300 automotive signal generator sensor
Size: 156.5*107*29mm
Product parameters:
1. Power supply: 12-24V
2. Voltage signal: 0-5V
3. Resistance signal: 0-10kΩ.
4. Oxygen sensor signal: 0.1-0.9V.
5. The sum of the two signals of the throttle position sensor is 5V.
6. The ratio of the two signals of the throttle pedal sensor is 2:1.
Color: Black
Material: plastic
Package Contents:
1 set Automotive Sensor Simulator
Detalii
| OPC | PVK98FB |
|---|---|
| Coduri | 6033495008606 (EAN) |
Date despre produs
| Height | 5cm |
|---|---|
| Width | 16.5cm |
| Length | 18.5cm |
| Weight | 0.3kg |
| Colour | Black |
| Material | Plastic |
