Waveshare UART Fingerprint Access Control Module Relay Board USB Dual Interface Secure Entry and Exit Management System
Varumärke Tlily
Ny
I lager
Varför du kommer att älska att handla på OnBuy:
- Tjäna Cashback på varje köp – använd den hur du vill. Spara, spendera eller ta ut.
- Fri frakt – på miljontals produkter på sajten
- Kunder älskar oss – 136,000 recensioner med betyget “Utmärkt”
417,38 kr
692,86 kr
Spara 40%!
FRI frakt
1 %
Tjäna 4,17 kr direkt
Läs mer
Priserna för varor som säljs av OnBuy inkluderar moms.
Räntefria betalningsalternativ finns tillgängliga
Se fullständig produktbeskrivning och detaljer
Leverans: Prioritet (Gratis) | mån 26e - fre 30e okt
Säljs av: CNNOTEPAD
Returer: 30 dagar
180 dagars betalningsskydd
Du kanske också gillar
Beskrivning & information
Sammanfattning
- Built-in commercial algorithm, supports fingerprint entry, fingerprint comparison, fingerprint image extraction and fingerprint feature value upload, etc., with stable performance and fast recognition speed
- Capacitive fingerprint recognition, sensitive sensing, the finger can be quickly recognized by just lightly touching the collection window
- High hardware integration, main control and fingerprint sensor integrated into one, easy to embed into small volume applications
- Built-in human body sensing device, with power-off sleep and touch wake-up functions, lower power consumption
- Onboard UART serial port and USB dual communication interface
Waveshare UART Fingerprint Access Control Module Relay Board USB Dual Interface Secure Entry and Exit Management System Beskrivning
Built-in commercial algorithm, supports fingerprint entry, fingerprint comparison, fingerprint image extraction and fingerprint feature value upload, etc., with stable performance and fast recognition speed
Capacitive fingerprint recognition, sensitive sensing, the finger can be quickly recognized by just lightly touching the collection window
High hardware integration, main control and fingerprint sensor integrated into one, easy to embed into small volume applications
Built-in human body sensing device, with power-off sleep and touch wake- functions, lower power consumption
Onboard UART serial port and USB dual communication interface
Sensor type:capacitive touch sensor
resolution:508DPI
image pixel array:192 x 192
Fingerprint template size:448 bytes
Sensor size:9.6 x 9.6 (mm)
Fingerprint capacity:1000 pieces
Comparison :Less than 0.5s (1:N, and N less than equal 500)
False recognition rate:Less than 0.001% (safety level 3)
rejection rate:Less than 2% (safety level 3)
Working voltage:3.3V
Working current:Less than 55mA
Static electricity test: IEC 61000-4-2 LEVEL 4 15KV air discharge
Communication interface:UART,USB
Communication baud rate:115200bps (support 9600bps-115200bps)
Color:As Shown
Material:ABS
Package Contents:
1 * capacitive touch sensor
Detaljer
| OPC | PVX8NBR |
|---|---|
| Varumärke | Tlily |
| Koder | 4711627482471 (EAN) |
| Produkt- och säkerhetsinformation |
Produktdata
| Height | 5cm |
|---|---|
| Width | 5cm |
| Length | 5cm |
| Weight | 0.1kg |
| Colour | As Shown |
| Material | ABS |
