BG95-M3 Zero Development Board IoT QuecPython GNSS Positioning LTE Cat Global Communication Development Board

BG95-M3 Zero Development Board IoT QuecPython GNSS Positioning LTE Cat Global Communication Development Board Popis

The main module of the BG95-M3 Zero development board is equipped with BG95, which supports the multi-mode (LTE Cat M1, LTE Cat NB2, EGPRS) LPWA module of the 3GPP Release 14 protocol specification. Under the LTE Cat M1 network, the module can support 588 kbps (Max) downlink rate and 1119 kbps (Max) uplink rate. It uses a built-in MCP and an ARM Cortex A7 processor that supports ThreadX system, with very low power consumption.
Onboard BG95-M3 main module, supports LTE Cat M1, LTE Cat NB2, EGPRS network
network, universal
Onboard 40PIN GPIO interface, compatible with most Raspberry Pi HAT expansion boards
Onboard 5 LED indicators for easy viewing of module operating status

Onboard Type-C interface, you can easily with the development board with just one USB Type-C data cable
Support PPP, TCP, UDP, SSL, TLS, FTP(S), HTTP(S), NITZ, , MQTT, LwM2M, COAP, IPv6 and other protocols
Support GNSS positioning (GPS, GLONASS, BDS, Galileo, QzSS)
Onboard SlM card slot supports 1.8V SIM card, designed close to the board for easy SIM card insertion and removal
Due to different batches, there may be differences in product appearance, color, and printed text, which will not affect the use.
Colour:Green
Material:PCB

Package Contents:
1 x development board
1 x USB cable
1 x connecting cable
1 x antenna
