ESP32-S3- Single-Core Modules SuperMini S3FH4R2 Development Board Super WiFi BT Module

ESP32-S3- Single-Core Modules SuperMini S3FH4R2 Development Board Super WiFi BT Module Popis

The SoC integrates a high-performance Xtensa 32-bit LX7 dual-core processor with a clock speed of to 240MHz
Supports 2.4GHz Wi-Fi (802.11 b/g/n) and Bluetooth 5 (LE)
Onboard antenna with miniature ceramic structure, easily integrated into user-designed baseboards
RF components, along with inductors, capacitors, and crystal oscillators, emphasize the stability of RF circuits
A stable power supply is achieved by using an LDO with filter capacitors to convert 5V to 3.3V

Supports flexible clock and individual module power settings to achieve low-power modes in multiple scenarios.
USB serial port full-speed controller with electrostatic discharge protection, featuring 34 GPIO pins for flexible configuration of peripheral functions.
It features 4 SPI, 2 I2C, 3 UART, 2 I2S, 2 ADCs, and 8 independent PWM.
Peripherals such as channels and two MCPWM units
(The product printed words may vary depending the batch, but this does not affect use)
Color: As Shown
Material: PCB

Package Contents:
1*ESP32-S3 board
