AD831 Active Mixer Module RF Mixer Module - 500MHz Low-Noise, High-Linearity RF Receiver Frequency Converter

AD831 Active Mixer Module RF Mixer Module - 500MHz Low-Noise, High-Linearity RF Receiver Frequency Converter Description

Wide Frequency Coverage: Supports RF and LO input frequencies from to 500 MHz; IF output reaches to 200 MHz (single-ended voltage output) or 250 MHz (differential current output), meeting the requirements of most high-frequency communication and signal processing applications.
High Linearity and Low Distortion: Features a third-order intercept point (IP3) of +24 dBm and a 1 dB compression point of +10 dBm; offers wide dynamic range and low third-order intermodulation distortion, making it suitable for demanding RF receiver systems.
Low LO Drive Requirement: Requires an LO input signal of only -10 dBm, eliminating the need for an external high-power driver; simplifies system design and reduces costs associated with shielding and isolation.
Flexible Power Supply and Interfaces: Supports dual (5V) or single power supply operation, with power consumption controllable via external circuitry; all support coupling, allowing for greater application flexibility.
Industrial-Grade Design: Housed in a precision CNC-machined aluminum enclosure that provides excellent shielding and heat dissipation; standard SMA connectors ensure secure connections and high signal integrity.

Ready-to-use modular design: Features integrated input/output matching and protection circuitry, eliminating the need for complex peripheral design and enabling rapid deployment in broadcasting, communications, TV heterodyne systems, and frequency synthesis equipment.

Parameters
Operating voltage: 5V (typical operating current: 100mA)
Operating frequency: RF/LO -500MHz; IF output -200MHz
Input/Output impedance: 50Ω
LO drive level: -10dBm
Interface type: SMA (male connector/external thread with inner hole)
Output format: Supports differential current output and single-ended voltage output
