Generator Controller Auto Start Programmable Configurable Fault Protection Diesel Generator Control Panel DSE720 DC8‑35V

Generator Controller Auto Start Programmable Configurable Fault Protection Diesel Generator Control Panel DSE720 DC8‑35V Description

Generator Controller Auto Start Programmable Configurable Fault Protection Diesel Generator Control Panel DSE720 DC8‑35V
Feature:
1. DIESEL GENERATOR CONTROLLER: This controller is used for diesel generators, with auto start function, providing a range of advanced engine monitoring and protection functions.
2. MULTI FUNCTION: This control panel can be used to monitor generator speed, frequency, voltage, current, oil pressure, coolant temperature, run time and battery voltage, etc.
3. FAULT PROTECTION: When the fault condition is detected, the controller will automatically shut down the engine and display the exact fault via LCD display or LED indicator.
4. PROGRAMMABLE AND CONFIGURABLE: The controller can be configured with computer through front panel or 810 interface for remote control, can also be programmed through front panel.
5. AUTOMATIC SWITCHOVER: The control module monitors the main power supply and will automatically switch to the generator when the main power supply fails.
Specification:
Item Type: Generator Controller
Material: ABS
Model: DSE720
Power Supply: DC8-35V
Current Consumption: 180mA(12V), 190mA(24V)
Voltage Input Range: AC15-333V, 50 or 60Hz
System Interior Programmable Control Output: Active DC, maximum 2.4A
Oil Valve and Motor Control Output: Active DC, maximum 3.4A.
Package List:
1 x
Generator Controller1 x Manual
