USBCAN I USB to CAN Adapter USB CAN Analyzer Debugger Supports Secondary Development Remote Upgrade

USBCAN I USB to CAN Adapter USB CAN Analyzer Debugger Supports Secondary Development Remote Upgrade Description

USB CAN debugger with 1-way CAN interface. PC can be connected to a standard CAN network through USB bus, build field bus test laboratory, industrial control, intelligent building, automotive electronics and other fields in data processing, data acquisition, data communication network CAN core control unit
USBCAN I can be used as a standard CAN node. It is a powerful tool for CAN bus product development, CAN bus device testing and data analysis; at the same , the USB CAN debugger boasts small size and enables easy installation. Thus, it is the best choice for portable system users
The debugger can directly configure, transmit and receive the CAN bus using the USBCAN tool software provided by our store. Users can also refer to the DLL dynamic connection library and routines provided by our store to write their own applications to facilitate the development of CAN system application software products

Features:
One-channel USB to CAN adapter
Support CANopen, J1939 and DeviceNet parsing
Supports secondary development and remote upgrade
The CAN channel adopts an electrical isolation design

Hardware Parameters:
Protocol conversion between USB and CAN bus;
USB interface supports USB2.0 and is compatible with USB1.1;
Support CAN2.0A and CAN2.0B protocols, standard frames and extended frames;
Support two-way transmission, CAN sending and CAN receiving;
Support data frame and remote frame format;
CAN controller baud rate is optional between 10Kbps-1Mbps, which can be configured via software;
The CAN transceiver adopts magnetic isolation with an isolation voltage of 2500V;
CAN controller with 3 transmit buffers, 8 hardware FIFO receiver buffers, and the maximum receiving capacity can reach 7000 frames / second;
Color: As Shown
Material: PCB

Package Contents:
