125kHz DC 9-12V Embedded ID Module RFID Contactless Card Reader

125kHz DC 9-12V Embedded ID Module RFID Contactless Card Reader Description

Parameters:

Working voltage:DC 9-12V

Working current:60mA~80mA

Reading range:5~10cm

Working temperature: -40??~60??

Cards capacity:2000PCS

Supporting card style:EM card

Working frequency:125KHz

Infrared operate:

 Enter program: press ??1234?? then press ??CALL??.

 Continuously add cars: press ??1??+??CALL??, green LED will blink, then read cards continuously.

 Continuously clear cards, press ??3?? +??CALL??, red LED will blink, then read cards continuously.

 Add Card with number: press ??0??+XXXXXXXXXX (10bit card chip number)+??CALL??.( while press ??0??,the green LED will light on, then press 10bit card chip number)

 Clear card with number: press ??2??+XXXXXXXXXX (10bit card chip number)+??CALL??,(while press ??2??,the red LED will light on, press 10 bit card chip number.)

 Clear all cards: press ??4?? +??CALL??, after several second, will hear ??B?? sound, clear finished.

 Door normal open start: press ??5?? +??CALL??

 Door normal close start: press ??6?? +??CALL??

 Open door once time: press ??7?? +??CALL??

 Change password: press ??8?? +XXXX (4bit password)+??CALL??.

 EXIT program: press ??EIXT??, or do not any operating, it will be auto-exit after 10s.

Package Included:

1*RFID Card Reader Module

Notes:

The product must have knowledge of circuit linking, no linking video will be provided. Thanks!
