15A V2 Brushless ESC RC Speed Controller 23S LiPo with Reverse Thrust and Stable 5V BEC

15A V2 Brushless ESC RC Speed Controller 23S LiPo with Reverse Thrust and Stable 5V BEC Description

15A V2 ESC Speed Controller (1PC) Compact, programmable ESC designed for small RC aircraft and multirotors that use 2 to 3S LiPo batteries. The unit combines a 32bit ARM M0 processor with an efficiencyfocused drive algorithm to deliver stable throttle response, lower operating temperature, and improved flight time. Key features and benefits performance processor: 32bit ARM M0 running up to 96 MHz, supporting motor speeds up to 300000 RPM for 2pole motors for precise control and fast response. Efficient drive control: Driving Efficiency Optimization reduces ESC heat, improves throttle stability and flexibility, and extends usable flight time. Programmable: settings via an independent programming cable or an LED programming box to match motor and airframe requirements. Reliable BEC output: Linear BEC delivering 5V at 2A for onboard electronics and receivers. Compact and lightweight: Net weight 10 g and dimensions 38 x 17 x 5 mm allow installation in tight spaces. Connector and control compatibility: Equipped with a 2.0 mm gold female output plug and supports remote control operation. Technical specifications Continuous current: 15A/30A Power input: 2 to 3S LiPo BEC mode: Linear BEC output: 5V at 2A Net weight: 10 g Size: 38 x 17 x 5 mm Output plug: 2.0 mm gold plug (female) Processor: 32bit ARM M0, up to 96 MHz, supports up to 300000 RPM (2pole motor) Programming interface: independent programming cable Programming options supported: LED programming box supported; LED setting card tuning not supported; LCD programming box tuning not supported Wireless and firmware limitations: WiFi module not supported; OTA programmer not supported; online firmware upgrade not supported Practical applications Small racing or freestyle quadcopters using 2S or 3S LiPo packs where compact size and low weight matter. Lightweight fixedwing or park flyer models that require a lowprofile ESC and a stable 5V BEC for receivers and servos. Replacement or upgrade in micro multirotor builds where improved throttle response and reduced ESC temperature are desired. Package contents 15A V2 ESC Speed Controller x 1 This ESC is intended for hobby RC use only. Follow proper wiring and programming procedures for your specific motor and airframe to ensure reliable operation.
