2.5K200MHz Clock Signal Generator Module, Frequency Square Wave Generator, Compatible TFT Display DIY

2.5K200MHz Clock Signal Generator Module, Frequency Square Wave Generator, Compatible TFT Display DIY Description

Key benefits Flexible widerange output: F0 and F1 can be set to the same frequency from 2.5 kHz to 200 MHz, enabling a single device to cover a broad set of RF tasks without multiple sources. Coherent multioutput with configurable division: F2 and F1 share a phaselocked loop (PLL); the frequency division ratio is configurable to tailor precise frequency relationships and synchronization between outputs. Simple, robust interface: Output via SMA female connector ensures reliable RF connections with standard test equipment. Easy to power and integrate: Designed to operate from a +5 V supply, compatible with common lab and bench equipment. Clear compatibility and performance: Directly suited for lab testing, development, and calibration scenarios requiring precise, configurable RF signals. Technical specifications Output frequencies: F0 = F1, range 2.5 kHz to 200 MHz PLL configuration: F2 and F1 share a phaselocked loop; the frequency division ratio is configurable Output interface: SMA female connector Power supply: +5 V Use scenarios RF component testing and characterization: Generate stable, adjustable test signals for filters, mixers, and amplifiers to verify performance across a broad frequency range. Calibration and alignment of lab instruments: Provide a consistent reference signal for calibrating analyzers, receivers, and measurement chains. Prototype development and multichannel experiments: Create synchronized RF signals for wireless, radar, or communication experiments that require precise frequency relationships between outputs. Notes All original product specifications and functions are preserved: F0 and F1 equality, the F2/F1 PLL sharing and configurable division ratio, SMA female output, and +5 V power supply.
