3D Printer Heated Bed MOSFET Expansion Module with 2-pin Connector compatible with Anet A8 A6 A2

3D Printer Heated Bed MOSFET Expansion Module with 2-pin Connector compatible with Anet A8 A6 A2 Description

1. It frequently occurs that after purchasing a 3D printer (especially the Anet A8, A6, and A2), the mainboard bears the entire load for heating the print bed. This poses a fire hazard, as the connectors are not designed for such high loads. 2. For this reason, the MOSFET module solves these problems by relieving the load from the mainboard. 3. It also resolves print quality issues, as the mainboard is not heavily overloaded by the power consumption required to heat the print bed. 4. It is not only used for the heated bed. It is very common for it to also be used for the extruder's heating elements.
2. Its main purpose is to relieve the load on the mainboard, making it more stable and interference-free.
3. Color: Black
4. Material: Plastic
5. If your total power consumption is 240W and you have a 12V power supply, this means that at least 20A are required (20 x 12 = 240W).
6. Since the control board is only rated for 15A, this setting will not work. To make it work, you need this additional power module.
7. This module can be used in both Chitu mainboards and other open 3D printer mainboards.
8. With normal cooling, this module operates stably at a maximum current I (Max) = 25A; The operating current should not exceed 25 A.
⑫ If you intend to use a heated bed with your 3D printer that uses a 12 V power supply, this module is recommended. Otherwise, excessive current may damage the connectors on the control board.
⑬ Compatible with Anet A8, A6, A2.
⑭ Package Contents:
1 x MOSFET Expansion Module
⑮ Note: Shooting conditions and different displays may cause the color of the item in the picture to be slightly different from the real color. Measurements allow an error of +/- 1-3 cm.
