433MHz 4ch RF Remote Relay Switch 12V 24V for DIY

433MHz 4ch RF Remote Relay Switch 12V 24V for DIY Description

1、Wide Use: 12V/24V learning code remote control switch, suitable for burglar alarm, remote control electric doors and Windows, signal control, industrial control, lifting equipment and other electrical control circuit. 2、Applicable: RF remote control switch module relay contact independent output, very suitable for direct control of various loads. 3、Smooth Operation: The RF switch transmitter uses learning code wireless coding technology (space to code), no direction, switch interference. 4、Working Mode: The wireless RF remote control has self lock, interlock, click user free adjustment, can realize one control more, more control one. 5、Superior Performance: The receiving plate can withstand 10A current in each circuit, and can directly drive DC and AC loads. Each relay switch has a set of normally open (normally closed) contacts.
Item Type: RF Remote Control
Material: ABS
Working Voltage: DC12V/24V (Jumper Adjustment)
Current: Standby Less Than 6mA, Operating Less Than 128mA
Operating Temperature: -10-+80
Receiver Frequency: 433MHZ
Reception Sensitivity: -105dB
Output Status: Switching Quantity
Maximum Load: 10A Relay, Resistive Load Less Than 8A, Inductive Load Less Than 3A
Remote Control Built In Button Battery: 4 x CR2016(75mAh)
2 x Remote Control
1 x Relay
