8 Channel Testing Fixture BC-8C for Button Cell Battery Analyzer Not Including Lines

8 Channel Testing Fixture BC-8C for Button Cell Battery Analyzer Not Including Lines Description

Features:
1. BATTERY1, BAT1+/BAT1-, SW1, LED1 correspond to 1 group, totaling 8 groups; Among them, BAT1+(red terminal)
For the positive output of the battery, BAT1- (black terminal) for the negative output of the battery
2. Battery insertion: Place the positive electrode of the button type battery to be tested upwards and the negative electrode downwards in a circular area, labeled BATTERY1-8, and
Confirm that the battery is centered and in close contact with the upper and lower electrode plates.

The BC-8 eight channel buckle battery test holder is suitable for performance testing of buckle batteries with a diameter of less than 25MM, and can also test 1-8 buckle batteries. It is convenient to install various button type batteries within the specification range into the clamp holder, and use the non self-locking button to detect whether the battery polarity is correctly connected and determine whether the battery is charged. Finally, the performance of the battery is tested by connecting to the battery analyzer.
Check if the battery is installed correctly:
Press the corresponding soft touch (SW), and the corresponding LED will light , indicating that the battery has been installed correctly;
If the corresponding LED light is not , check if the battery polarity is installed correctly or determine if the battery is charged.
Color: Black
Material: plastic

Package Contents:
1 x Battery Analyzer
