AMG8833 infrared thermal sensor module 88 0–80

AMG8833 infrared thermal sensor module 88 0–80 Description

Two dimensional area temperature detection: 8 x 8 (64 pixels), I2C digital output (temperature value output capability) The AMG8833 thermal imaging camera sensor has a temperature measurement range of 0 C to 80 C (32 F to 176 F) and an accuracy of 2.5 C (4.5 F) There is a configurable interrupt pin, which can be triggered when any single pixel is higher or lower than the threshold value you set There is a configurable interrupt pin, which can be triggered when any single pixel is higher or lower than the threshold value you set It can detect humans from a distance of 7 meters (23 feet). The maximum frame rate is 10Hz, which is very suitable for creating your own human detector or mini thermal imager. Applicable to high function household appliances (microwave oven and conditioner), office energy saving ( conditioner/lighting control), digital signs, automatic doors/elevators color:Blue Material:pcb Package Contents: 1 x Thermal Imager Sensor Only the above package content, other products are not included. Note: Light reflection and different displays may cause the color of the item in the picture a little different from the real thing. The measurement allowed error is +/- 1-3cm.
