Battery Capacity Tester FX35 5A 35W Electronic Load USB Power Adjustable Resistor LCD Display

Battery Capacity Tester FX35 5A 35W Electronic Load USB Power Adjustable Resistor LCD Display Description

1. LCD Display: In normal mode, the upper line of the LCD screen displays the load input voltage and load temperature; the lower line displays the load current, power, capacity and discharge time. In protection mode, the LCD screen displays the protection code. In setting mode, the LCD screen displays the setting parameter codes and parameter thresholds.
2. Load current adjustment: The discharge current can be adjusted by the potentiometer.
3. Sound and light alarm: When the load is turned on, the RUN indicator light is always on and the buzzer does not sound; when the load is turned off, the RUN indicator light is not on and the buzzer does not sound. After entering the protection mode, the buzzer beeps and the RUN indicator light flashes.
4. Intelligent fan cooling: It automatically starts when the load discharge power is 10W or the load temperature is 40.
5. Complete software and hardware protection mechanism, and the software protection threshold can be adjusted. After software protection, the output is turned off.

Hardware protection:
Both the module power supply port and the load input port have anti-reverse connection protection.
Software protection:
OVP overvoltage protection
OCP overcurrent protection;
OPP overpower protection
OTP overtemperature protection
undervoltage protection
The load is turned off by default. the ON/SET button to or turn off after power-on.
All settable parameters can be stored after power-off.
Color:Blue
Material:ABS

Package Contents:
1 * FX2535 constant current tester

Only the above package content, other products are not included.
Note: Light reflection and different displays may cause the color of the item in the picture a little different from the real thing. The measurement allowed error is +/- 1-3cm.
