Brushless ESC 128KHz 2-8S Lipo 120A 7-33.6V Speed Controller

Brushless ESC 128KHz 2-8S Lipo 120A 7-33.6V Speed Controller Description

1、High Performance Processor: Equipped with a 32 bit STM32G071 processor running at up to 64MHz, supporting motor PWM frequencies up to 128KHz for accurate control. 2、Efficient Heat Dissipation: Utilizing high power for MOSFET and CNC metal heat sink, ensuring stable operation even under heavy current loads with effective heat dissipation. 3、Versatile Motion Modes: Supports multiple motion modes including unidirectional, bidirectional, and brake mode for various motor applications. 4、Comprehensive Safety: The brushless electronic speed controller (ESC) is designed with multiple layers of safety including low voltage cutoff, overheat safety, stall detection, and current limiting to ensure the longevity and safety of your motors and equipment during operation. 5、Signal Compatibility: Automatically detects throttle signals upon power up, supporting various signal protocols such as for Dshot, for PWM, for Oneshot, and for Multishot for flexible compatibility. 6、Visual Programming Tool: User friendly interface for easy motor angle adjustment, throttle calibration, current monitoring, motor direction setting, and telemetry signal configuration. 7、Customizable RGB LED Lighting: The built in RGB LED lighting system allows users to personalize their setup with a wide range of color options. Whether you want to match your drone's color scheme or simply add a touch of flair, the programmable LED lights provide endless possibilities for customization and creativity. 8、Versatile Applications: This brushless electronic speed controller is widely used in various fields, including agricultural drone spraying, aerial photography with multirotor UAVs, remote control model boats for leisure, and high speed RC model cars for racing enthusiasts. With its versatility and reliability, this controller is a perfect fit for a wide range of hobbyist and professional applications.
Item Type: Brushless Motor ESC
Material: PCB
Model: 28120 (BLHeli 32)
Processor: STM32G071
Input Voltage: DC 7V-33.6V (2 to 8S Lipo)
Continuous Current (Good Heat Dissipation) : 120A
Maximum Current (Good Heat Dissipation) : 150A
Supported Firmware: for BLHeli 32
Signal Protocols: for Dshot (all), for PWM, for Oneshot, for Multishot, etc.
Programming Parameters: Supported
Throttle Calibration: Supported
Advance Angle Settings: Supported
Current Detection: Supported
Telemetry Signal: Supported
Motor Steering Settings: Supported
RGB LED Color Light: Supported
Application Scenarios: Suitable for multi axes drones, fixed wing aircraft models, multi rotor drones, plant safety machines, model ships, RC model cars, and rock crawlers.
1 x Electronic Speed Controller
1 x 2P Signal Cable
4 x Heat Shrink Tubing
