CC68-C1 433mhz LLCC68 LoRa Module Full Instead of LORA1262/LORA1268

CC68-C1 433mhz LLCC68 LoRa Module Full Instead of LORA1262/LORA1268 Description

Maximum output power: 22 dBm(160mW)
Industrial grade high precision crystal oscillator.
LoRa,(G).
255 bytes .
Data transfer rate: 0.6-300 Kbps @;1.76-62.5 Kbps @Lora

The CC68-C1 wireless module uses 's LLCC68 device, ultra-low receive current and sleep current, and sensitivity of -129dBm. Built-in 64KHz crystal oscillator can wake up microcontroller periodically under low power consumption. The module antenna switch is integrated and controlled by chip, which saves resources of external MCU. The compact size and 22dBm (160mW) output power have great advantages in IoT and battery-powered applications.
Frequency Range:433mhz
Sensitivity:-129dBm @LoRa
Application:
Remote meter reading
Industrial control
Home automation remote sensing
Toys control
Sensor network
Tire pressure monitoring
Health monitoring
Wireless PC peripherals
Due to different product batches, the appearance , which does not affect use.
Colour:As Shown
Material:PC

Package Contents:
1 * Module

Only above package content, other products are not included.
Note: Light reflection and different displays may cause color of item in picture a little different from real thing. The measurement allowed error is +/- 1-3cm.
