Clock Signal Generator Module 2.5K200MHz Frequency Square Wave Generator With TFT Display For DIY Kit

Clock Signal Generator Module 2.5K200MHz Frequency Square Wave Generator With TFT Display For DIY Kit Description

Output interface: SMA female connector Output frequency: F0 = F1 = 2.5K to 200MHz; F2 and F1 share a phaselocked loop, and the frequency division ratio can be configured Power supply: +5V Benefits and features Flexible widerange frequency generation Generates signals for F0 and F1 across 2.5K to 200MHz, enabling use across multiple RF test and development scenarios PLL based frequency control F2 shares a PLL with F1, with a configurable division ratio to achieve precise and repeatable output frequencies Standardized output interface SMA female connector ensures compatibility with common RF test equipment, cables, and measurement instruments Simple power requirements Operates from a +5V supply, allowing easy integration with typical lab power sources and development boards Clear and predictable behavior The configuration of the division ratio and the PLLbacked outputs provides stable, repeatable signals suitable for bench testing and calibration Use scenarios RF lab signal generation and measurement Use as a controllable RF source to feed mixers, amplifiers, filters, and receivers for characterization and testing PLL and frequency synthesis verification Verify timing, synchronization, and frequency planning in RF modules and communication system development Prototyping and bench experiments Serve as a versatile signal source for wireless and wired communication system experiments, timing references, and benchlevel demonstrations Notes The description reflects the stated interfaces, frequency range, PLL relationship, division ratio configurability, and power requirements No additional features or specifications beyond the provided information are included
