DIY Encoder Gear Motor with Mounting Bracket 65mm

DIY Encoder Gear Motor with Mounting Bracket 65mm Description

DIY Encoder Gear Motor with Mounting Bracket 65mm Wheel Kit for Smart Car Robot DC12V(500RPM)



1、It is made of high-accuracy one-time forming rotor high-quality materials with high conductivity, wear resistance and long life. 2、High-quality carbon brushes have good commutation performance, long service life, good electrical and thermal conductivity and good lubrication performance. 3、High-strength magnetic tile has long service life, strong power and greater torsion. It adopts fully enclosed structure to prevent dust from entering the motor. It has simple structure, convenient maintenance and small volume, which can effectively reduc 4、The gearbox is made of high-quality metal gears, which has good impact resistance and durability to reduce noise, thus delaying the service life of the gearbox. 5、Suitable for smart car, robots and printers



Features: 1. It is made of high-accuracy one-time forming rotor high-quality materials with high conductivity, wear resistance and long life. 2. High-quality carbon brushes have good commutation performance, long service life, good electrical and thermal conductivity and good lubrication performance. 3. High-strength magnetic tile has long service life, strong power and greater torsion. It adopts fully enclosed structure to prevent dust from entering the motor. It has simple structure, convenient maintenance and small volume, which can effectively reduce weight, save space and be reliable. 4. The gearbox is made of high-quality metal gears, which has good impact resistance and durability to reduce noise, thus delaying the service life of the gearbox. 5. Suitable for smart car, robots and printers Specification: Condition: 100% Brand new ReductionRatio No-Load Rated Locked-Rotor L Size Rated Voltage Speed Current Speed Current Torsion Torsion Current V 10%RPM A 10%RPM A KG.CM KG.CM A MM 4.4 24 1360 0.04 1000 0.16 0.1 0.4 0.6 18 9.6 24 620 0.04 500 0.16 0.2 0.9 0.6 17.5 21.3 24 280 0.04 200 0.16 0.4 2 0.6 19 35.5 24 170 0.04 130 0.16 0.69 3.3 0.6 21 46.8 24 130 0.04 100 0.16 0.9 4.4 0.6 21 78 24 77 0.04 60 0.16 1.5 5.5 0.6 23 103 24 60 0.04 50 0.16 2 7.3 0.6 23 130 24 46 0.04 40 0.16 2.5 9.2 0.6 25 171 24 35 0.04 30 0.16 3.3 Do not block or instantaneous load reversal 25 226 24 26 0.04 20 0.16 4.4 25 377 24 16 0.04 15 0.16 7.3 27 500 24 12 0.04 10 0.16 9.7 27 Optional Style: 1000RPM, 500RPM, 200RPM, 130RPM, 100RPM, 60RPM, 50RPM, 40RPM, 30RPM, 20RPM, 15RPM, 10RPM Package List: 1 x Motor 1 x Motor Base 1 x Tire 1 x Coupling 1 x Hex Wrench 2 x Coupling Screw 6 x Small Screw 1 x Large Screw
