Flipper Zero 2.4G/5G WiFi Module Development Wireless Board BW16 RTL8720DN

Flipper Zero 2.4G/5G WiFi Module Development Wireless Board BW16 RTL8720DN Description

Features:

Supported Protocols: 802.11 a/b/g/n, dual-band (2.4GHz and 5GHz)

Transmit Power:

2.4GHz: Up to 16dBm (11b), 15dBm (11g), 14dBm (11n)

5GHz: Up to 14dBm (11a), 13dBm (11n)

(Based on the open-source project FlipperZero-WiFi-Scanner_Module)

Real-time scanning of 5GHz channel strength (-60dBm to -75dBm dynamic display)

Proprietary dual-band sniffing algorithm supports intelligent switching between 2.4GHz and 5GHz sub-bands

Compatible only with WPA2 encryption protocols (pre-installed KRACK-resistant firmware)

Open API interface supports secondary development with Arduino/PlatformIO

Geek-level control experience

Companion app supports multiple target SSIDs (with signal strength/encryption type visualization)

Product Specifications:

Development Board Model: BW16-Kit

Compatible Module: BW16

Antenna Type: On-board PCB antenna

Spectrum Range: 2400-2483.5MHz or 5180-5825MHz

WiFi: Supports 802.11a/b/g/n

Bluetooth: BLE 5.0

Operating Environment: -40C to 85C

Storage Environment: -40C to 125C, <90% RH

Power Supply Range: 5V supply voltage, current >500mA

Security: AES/DES/SHA

Flash: 4MB

Package Includes:

1x Expansion Board Module

1x Type-C Cable
