FS200‑SHT10‑03 Soil Temperature and Humidity

FS200‑SHT10‑03 Soil Temperature and Humidity Description

FS200‑SHT10‑03 Soil Temperature and Humidity Sensor Probe for SHT1 Series



1、Digital, the resolution is up to 14bit 2、Internal self calibration 3、The temperature and humidity are closely combined, convenient for dew point measurement 4、High reliability and long term stability 5、The product structure is exquisitely, suitable for field application and product integration



Descriptions: Soil temperature and humidity probe using the original temperature and humidity sensors as the core component, can be directly connected to the single-chip microcomputer to use .With very high consistency, can be completely interchangeable. the probe has the characteristic of temperature resistance, pressure resistance, loss of ability, suit to the agricultural greenhouse, flowers, nursery garden, lawn and other need detection of soil temperature and humidity environment occasions. Features: Digital, the resolution is up to 14bit. Internal self calibration. The temperature and humidity are closely combined, convenient for dew point measurement. High reliability and long term stability. The product structure is exquisitely, suitable for field application and product integration. Applied in the agricultural greenhouse, flowers, nursery garden, lawn and other need detection of soil temperature and humidity environment occasions. Specifications: Model: FS200-SHT10-03 Type: temperature and humidity Production process: integration Output signal: numeric type Technical parameters: Operating current: 15mA Temperature measuring range: - 20 ~ 100 Humidity measuring range: 0 ~ 100 % RH Working conditions: - 20 ~ 90 , 0 ~ 99% RH Storage conditions: - 20 ~ 80 , 0 ~ 95% RH Weight: 70g Package Included: 1 x FS200-SHT10-03 Soil temperature and humidity sensor
