Sorry, this item is temporarily out of stock.
GIGABYTE 850W GOLD FULLY UD850GM PG5 V2
Brand Gigabyte
New
£143.98
Similar Products we think you'll like
Would you like us to let you know when it's back?
Description & Details
GIGABYTE 850W GOLD FULLY UD850GM PG5 V2 Description
GIGABYTE 850W GOLD FULLY UD850GM PG5 V2
Details
| OPC | PFZ5KN5 |
|---|---|
| Brand | |
| Codes | 4719331553166 (EAN) |
External product information
Disclaimer: The information below is provided by various external sources and should be used as a guide only.
Detailed Product Information
Weight & dimensions
| Weight | 2.4 kg |
|---|---|
| Height | 86 mm |
| Width | 150 mm |
| Depth | 140 mm |
Performance
| Mean time between failures (MTBF) | 100000 h |
|---|---|
| Noise level | 40 dB |
| Purpose | PC |
| Bearing technology | HYB |
| ATX version | 3.1 |
| 80 PLUS certification | 80 PLUS Gold |
| Power supply unit (PSU) form factor | ATX |
Packaging data
| Package weight | 2.56 kg |
|---|---|
| Package depth | 269 mm |
| Package height | 211 mm |
| Package width | 618 mm |
| Package type | Box |
Design
| Product colour | Black |
|---|---|
| Illumination | No |
| Number of fans | 1 fan(s) |
| On/off switch | Yes |
| Cooling type | Active |
| Fan diameter | 12 cm |
| Fan location | Top |
Ports & interfaces
| PCI Express connector | Yes |
|---|---|
| Motherboard power connector | 20+4 pin ATX |
| Floppy drive power connector | 1 |
| Number of SATA power connectors | 8 |
| Peripheral (Molex) power connectors (4-pin) | 3 |
| ATX power connector (20+4 pin) | Yes |
| CPU power connector (4+4 pin) | Yes |
| PCI Express power connectors (6+2 pin) | 4 |
| Cabling type | Fully-Modular |
| Number of PATA power connectors | 3 |
| Motherboard power cable length | 61 cm |
| SATA power cable length | 150,600 mm |
| CPU power cable length | 60 cm |
| Peripheral (Molex) power cable length | 150,500 mm |
| PCI Express power cable length | 70 cm |
| PCI Express power connectors (16-pin) | 1 |
| Number of EPS connectors | 2 |
Power
| Input current | 12 - 6 A |
|---|---|
| Efficiency | 90% |
| Hold time | 16 ms |
| Power protection features | Over current, Over power, Over voltage, Overheating, Short circuit, Under voltage |
| Power factor | 0.9 |
| Power Factor Correction (PFC) type | Active |
| Combined power (+3.3V) | 105 W |
| Combined power (+12V) | 850 W |
| Combined power (+5V) | 105 W |
| Combined power (-12V) | 3.6 W |
| Combined power (+5Vsb) | 15 W |
| Max output current (+3.3V) | 20 A |
| Max output current (+12V) | 70.8 A |
| Max output current (+5V) | 20 A |
| Max output current (-12V) | 0.3 A |
| Max output current (+5Vsb) | 3 A |
| AC input frequency | 50/60 Hz |
| AC input voltage | 100 - 240 V |
| Total power | 850 W |
| Maximum input current (@110V) | 6 A |
| Maximum input current (@220V) | 12 A |
Packaging content
| Cable tie(s) included | Yes |
|---|
Logistics data
| Warranty period | 10 year(s) |
|---|
Certificates
| Compliance certificates | CCC, CE, Federal Communications Commission (FCC), RoHS |
|---|
Would you like us to let you know when it's back?
GIGABYTE 850W GOLD FULLY UD850GM PG5 V2
New
£143.98
