Global Version Relay GPS Tracker Real Time GSM Locator Anti-theft Cut off Fuel Power System Function

Global Version Relay GPS Tracker Real Time GSM Locator Anti-theft Cut off Fuel Power System Function Description

GPS and Russian GLONASS dual-mode positioning.
Real-time tracking.
against pseudo base-station&detect.
Vibration/Displacement/Low battery/Power off/over speed alert.
Main power cut off alert.
Geo-fence.
History Route.
Cut and resumeFuelPumpremotely.
AGPS locating.
Functions and Product parameters (Relay GPS Tracker CJ720/ Off petrol and electricity).

Specification:
Terminal size: 31x 31x 57mm.
System Language: Chinese/English.
Net Weight: 50g.
Backup Battery: 3.7V 100mAh.
Network: GSM/GPRS,
Network Band: 850/900/1800/1900Mhz.
Support: 4-frequencyGSM850/900/1800/1900MHzwhichcanworkworldwide.
GPS sensitivity: -159dBm.
GPS position accuracy: 10m.
First positioning time: Cold start 45-120 seconds.
Warm start: 35 seconds.
Hot start: 1 second.
Operating voltage: 10-50V input.
Oil-cutting function: Voltage is 5-15V, Current <10A.

Battery: Built-in lithium battery 3.7V 110mAh.
Storage temperature: -40C to +85C.
Operating temperature: -20C to +55C.
Humidity: 5% - 95% Non-solidified.
Power Consumption:
The power consumption is about 40 mA at work, and 1 mA at sleep.
The instantaneous current of the fuel and electricity part is up to 45A.

Special Note:
FUELPump line search.
Need professionals.
Or auto mechanic repair shop to help find.
Power supply,FuelPumpcut control line.
(1) The standard power supply of this equipment is 10V-50VDC, the red wire is the positive pole of the power supply,
and the yellow (black) is the negative pole of the power supply;
when installing the negative pole of the power supply, please select the grounding or grounding separately,
and do not share with other ground lines;
(2) The Fuel Pump cutoff control line (green/blue line) is connected to the Fuel Pump line.

Package Included:
1 X Relay GPS Tracker
1 X Manual
