Indicator 04 mm Range, 0.01 mm Resolution, Dovetail Rails Mount, Metric Precision Test Indicator

Indicator 04 mm Range, 0.01 mm Resolution, Dovetail Rails Mount, Metric Precision Test Indicator Description

240degree bidirectional measurement Accuracy 0.01 mm Max measuring range 00.8 mm This dial test indicator is designed for measurement during machining, layout and inspection work Benefits Bidirectional reading with a 240degree measurement range allows reading in either direction around the dial, reducing the need to reposition the instrument during measurement precision of 0.01 mm provides reliable tolerance verification for small features and assemblies Small measuring range of 00.8 mm is well suited for checking tiny gaps, steps, offsets, and fine dimensional features Simple, robust instrument intended for use in workshop environments during machining, layout and inspection tasks Specifications at a glance Range: 0 to 0.8 mm Resolution/Accuracy: 0.01 mm Measurement direction: bidirectional with 240degree range Application: machining, layout, and inspection work Use scenarios Machining setup and verification During milling or turning, use the indicator to confirm surface heights, step dimensions, and feature offsets between related features. This helps verify that the machined part conforms to design intent before proceeding to subsequent operations. Layout and alignment In fixture setup or layout tasks, mount the indicator to check datum alignment and verify that critical features are positioned within tolerance relative to reference surfaces. The bidirectional readout supports quick checks without repositioning. Quality inspection and QA In final inspection, measure small features and verify tolerances on finished parts. The 0.01 mm accuracy supports precision checks and helps confirm that components meet specification before release.
