Infrared Sensor Simple Thermal Imager 1.8"LCD Resolution Clear Definition Camera

Infrared Sensor Simple Thermal Imager 1.8"LCD Resolution Clear Definition Camera Description

Features:

This product combines the functions of surface temperature measurement and real-time thermal imaging, suitable for contactless temperature measurement, human temperature detection function, ambient temperature detection, industry parts temperature detection function.

With integrated design, compact, lightweight, and portable, it is easy to carry and does not take up too much space, it can operate smoothly without external devices.

Its uses FR4 epoxy outershell material for better protecting internal component and has a long service lifespan.

Adopts a high sensitive infrared sensor, 32*24 pixel far infrared array, clearly imaging.

1.8 inch LCD color screen, with 240*320 resolution, clearly displays and tracks the maximum temperature, the minimum temperature, and the center point temperature.

Real-time measurement, with -40?? to +300?? measurement ranges, and an 8Hz dynamic refresh rate.

This thermal imager has a photo-taking function, for which need to maintain at least 15S time.

Built-in a lithium-ion battery, USB Type-C cable charging design, with long battery lifespan.

Wide Applications:

High-precise contactless temperature measurement and body temperature detection.

Intelligent ambient temperature measurement and control of buildings.

Car repairs and maintenance inspection, automotive parts temperature detection.

Microwave oven and oven temperature detection and control.

Temperature monitoring of industrial parts.

Visual temperature sensors.

Floor heating equipment side leakage and maintenance.

Thermal inspection of circuit board and component.

Specifications:

Name: Thermal Imager

Materials: epoxy sheet + printed circuit board

Infrared sensor: MLX90640ESF-BAB

Display: 1.8inch LCD display

Screen resolution: 240*320 pixels

Temperature measurement range: -40?? to 300??

Measurement accuracy: ??2??

Refresh rate: 8Hz

Field of view: 55?? horizontal * 35?? vertical

Charging interface: Type-C

Packaging includes:

1*Thermal Imager

1*USB Cable

1*Screen Wipe
