Intel Core i5-12500 processor 18 MB Smart Cache Box

Name: Intel Core i5-12500 processor 18 MB Smart Cache Box
Brand: Intel
SKU: P9VR7TW
Price: 288.6000 GBP
Availability: OutOfStock

By Intel

New

£288.60

Similar Products we think you'll like

Computer Processors Intel Processors

Would you like us to let you know when it's back?

Add to Basket

Description & Details

Intel Core i5-12500 processor 18 MB Smart Cache Box Description

Intel Core i5-12500. Processor family: Intel® Core™ i5, Processor socket: LGA 1700, Processor manufacturer: Intel. Memory channels: Dual-channel, Maximum internal memory supported by processor: 128 GB, Memory types supported by processor: DDR4-SDRAM,DDR5-SDRAM. On-board graphics adapter model: Intel UHD Graphics 770, On-board graphics adapter outputs supported: Embedded DisplayPort (eDP) 1.4b,DisplayPort 1.4a,HDMI 2.1, On-board graphics adapter base frequency: 300 MHz. Market segment: Desktop, Use conditions: PC/Client/Tablet, PCI Express configurations: 1x16+1x4,2x8+1x4. Package type: Retail box

Details

OPC	P9VR7TW
Brand	Intel
Codes	5032037238564 (EAN)
MPN	Intel/BX8071512500
Links	Intel Processors

External product information

Disclaimer: The information below is provided by various external sources and should be used as a guide only.

Detailed product information

Processor

Processor model	i5-12500
Processor manufacturer	Intel
Processor family	Intel® Core™ i5
Box	Yes
Processor socket	LGA 1700
Processor cores	6
Processor threads	12
Processor operating modes	64-bit
Processor boost frequency	4.6 GHz
Processor cache	18 MB
Bus type	DMI4
Processor codename	Alder Lake
Processor cache type	Smart Cache
Memory bandwidth supported by processor (max)	76.8 GB/s
Processor ARK ID	96144
Cooler included	No
Performance cores	6
Maximum number of DMI lanes	8
Processor base power	65 W
Maximum turbo power	117 W
Performance-core base frequency	3 GHz
Performance-core boost frequency	4.6 GHz
Processor generation	12th gen Intel® Core™ i5

Weight & dimensions

Weight	350 g
Height	105 mm
Width	79 mm
Depth	121 mm
Processor package size	45 x 37.5 mm

Packaging data

Package weight	458 g
Package type	Retail box

Other features

Maximum internal memory	128 GB
Graphics output	eDP 1.4b, DP 1.4a, HDMI 2.1

Memory

ECC	Yes
Memory bandwidth (max)	76.8 GB/s
Memory channels	Dual-channel
Maximum internal memory supported by processor	128 GB
Memory types supported by processor	DDR4-SDRAM, DDR5-SDRAM

Features

Supported instruction sets	SSE4.1, SSE4.2, AVX 2.0
PCI Express slots version	5.0, 4.0
Execute Disable Bit	Yes
Idle States	Yes
Thermal Monitoring Technologies	Yes
Scalability	1S
CPU configuration (max)	1
Embedded options available	No
PCI Express configurations	1x16+1x4, 2x8+1x4
Maximum number of PCI Express lanes	20
Market segment	Desktop
Export Control Classification Number (ECCN)	5A992CN3
Commodity Classification Automated Tracking System (CCATS)	G167599
Use conditions	PC/Client/Tablet, Workstation
Direct Media Interface (DMI) Revision	4.0

Graphics

On-board graphics card model	Intel UHD Graphics 770
Discrete graphics card model	Not available
On-board graphics card	Yes
On-board graphics card base frequency	300 MHz
On-board graphics card dynamic frequency (max)	1450 MHz
On-board graphics card outputs supported	Embedded DisplayPort (eDP) 1.4b, DisplayPort 1.4a, HDMI 2.1
On-board graphics card maximum resolution (DisplayPort)	7680 x 4320 pixels
Number of execution units	32
On-board graphics card ID	0x4690
On-board graphics card maximum resolution (eDP - Integrated Flat Panel)	5120 x 3200 pixels
On-board graphics card refresh rate at maximum resolution (eDP - Integrated Flat Panel)	120 Hz
On-board graphics card refresh rate at maximum resolution (DisplayPort)	60 Hz
On-board graphics card refresh rate at maximum resolution (HDMI)	60 Hz
Number of displays supported (on-board graphics)	4
On-board graphics card maximum resolution (HDMI)	4096 x 2160 pixels
On-board graphics card DirectX version	12.0
On-board graphics card OpenGL version	4.5
Discrete graphics card	No
Multi-Format Codec Engines	2

Processor special features

Intel® Hyper Threading Technology (Intel® HT Technology)	Yes
Intel® Turbo Boost Technology	2.0
Intel® Quick Sync Video Technology	Yes
Intel® Clear Video HD Technology (Intel® CVT HD)	Yes
Intel® AES New Instructions (Intel® AES-NI)	Yes
Enhanced Intel SpeedStep Technology	Yes
Intel Trusted Execution Technology	Yes
Intel® Active Management Technology (Intel® AMT)	Yes
Intel VT-x with Extended Page Tables (EPT)	Yes
Intel® Secure Key	Yes
Intel 64	Yes
Intel Stable Image Platform Program (SIPP)	Yes
Intel® OS Guard	Yes
Intel Virtualization Technology for Directed I/O (VT-d)	Yes
Intel Virtualization Technology (VT-x)	Yes
Intel Turbo Boost Max Technology 3.0	No
Intel® Optane™ Memory Ready	Yes
Intel® Speed Shift Technology	Yes
Intel® Boot Guard	Yes
Intel® vPro™ Platform Eligibility	Yes
Mode-based Execute Control (MBE)	Yes
Intel® Deep Learning Boost (Intel® DL Boost)	Yes
Intel® Volume Management Device (VMD)	Yes
Intel® Control-flow Enforcement Technology (CET)	Yes
Intel® Total Memory Encryption	Yes
Intel® Thread Director	No
Intel® Gaussian & Neural Accelerator (Intel® GNA) 3.0	Yes
Intel vPro® Enterprise Platform Eligibility	Yes
Intel® Threat Detection Technology (TDT)	Yes
Intel® Standard Manageability (ISM)	Yes
Intel® One-Click Recovery	Yes
Intel® Hardware Shield Eligibility	Yes
Intel® Total Memory Encryption - Multi Key	Yes
Intel® Virtualization Technology with Redirect Protection (VT-rp)	Yes
Intel vPro® Essentials Platform Eligibility	Yes
