IP66 Marine Switch Panel (6-Way)

IP66 Marine Switch Panel (6-Way) Description

These units feature the attractive tactile rocker switches that are common on luxury Australian and foreign made motor cruisers. The panels have Butyl rubber gaskets and IP66 water resistant rated switches and circuit breakers, making these switch panels suitable for an exposed environment. They are pre-wired as much as possible, with wiring connections made via standard spade terminals for ease. The 4 way panel measures 120H x 130W and the 6 way 130W x 170H. Both require about 80mm of space behind the mounting bulkhead. The 4 way has 6,10,15 & 20A rated circuit breakers and the 6 way has 6,6,10,10,15 & 20A breakers, and the switches feature LED illumination to let you know which circuit is active. Moulded from ABS plastic, black in colour.

• DC Voltage : 12V, 24V
• IP Rating : IP66
• IP Rating certificate : true
• Length : 170mm
• Width : 130mm
• EDAU Primary Procurement Location : DCNEC - edau NSW Eastern Creek WH
• EDNZ Primary Procurement Location : DCAUK - ednz NZ Auckland WH
• AU Buffer Control : NOBUFF - No Buffer Control
• NZ Buffer Control : NOBUFF - No Buffer Control
• Stock Item Type : M Stockable Product
• Edit Status : Save
• Switch Type : Rocker
• Throws / Positions : 1pos
• Switch Connection : Spade Terminals
• Switch Colour Coded : Black
• Mechanism Material : ABS Plastic (Acrylonitrile Butadiene Styrene)
• Number of Switches : 6pc
• Individual Circuit Breakers : 6A, 20A
