Lora1278-C1 433Mhz Wireless Module Communication Module SX1278 Wireless IoT Module for Smart Homes

Lora1278-C1 433Mhz Wireless Module Communication Module SX1278 Wireless IoT Module for Smart Homes Description

The LoRa1278-C1 wireless module uses for 's SX1278 device, which adopts LoRa TM spread spectrum modulation frequency hopping technology to achieve efficient receiving sensitivity and strong anti-interference performance. Its communication distance and receiving sensitivity far exceed the current FSK and GFSK modulation. Multiple transmitted signals occupy the same channel without being affected, and it has strong anti-interference performance.
Sensitivity up to -139dBm
Maximum output power: 20dBm
Low receive current: 10.3mA

Sleep current Less than 200nA
Data transfer rate:
@FSK, 1.2-300kbps
@Lora TM,0.018-37.5kbps
Lora TM, FSK, GFSK, and OOK modulation modes
1.8-3.7 V power supply
127dB dynamic range RSSI
256-byte FIFO with frequency hopping function
Built-in temperature sensor and low battery indicator
Non-blocking signal
Operating temperature range: -40-+85
Product Applications:
Remote Control
Remote Meter Reading
Home Security Alarm and Remote Keyless Entry
Industrial Control
Home Automation Telemetry
Personal Data Logging
Toy Control
Sensor Networks
Tire Pressure Monitoring
Health Monitoring
Wireless PC Peripherals
Tag
Frequency range: 433MHz
Color:As Shown
Material:PCB

Package Contents:
1 * Wireless Module

Only the above package content, other products are not included.
Note: Light reflection and different displays may cause the color of the item in the picture a little different from the real thing. The measurement allowed error is +/- 1-3cm.
