MOS Driver Module DC 3.7V-27V PWM Output 3-20V Input PLC Drive Board

MOS Driver Module DC 3.7V-27V PWM Output 3-20V Input PLC Drive Board Description

Features:

Wide Application

Can be widely applied to control high power equipment

Motors,bulbs,LED light strips,DC motors,micro water pumps,solenoid valves,etc

Simple Operation

Clear interface will largely simplify the wiring

While the input signal and output indicator lights will better display the working status

Easy to Install

Comes with a light weight and a compact size as well

The convenient installation can be quickly completed within several minutes

Specification:

Input signal:PWM signal between 3~20V

Output capacity:DC 3.7V~27V,current within 10A per circuit

PWM frequency:0~20KHZ

Indicator light:with input signal and output indicator light

Application Note

The output can control high power devices,motors,light bulbs,LED light strips

DC motors,miniature water pumps,solenoid valves,etc

It can input PWM to control the motor speed,the brightness of the lights and so on

Module interface description:

1.DC+:positive DC power supply of the device

2.DC-:equipment DC power supply negative pole

3.PWM:signal input(connected to the microcontroller IO port,PLC interface,DC power supply,etc)

4.GND:Negative end of the signal

5.OUT+:positive output terminal(connected to the positive pole of the device)

6.OUT-:Negative output terminal(connected to the negative pole of the device)
