MPPT Solar Charge Controller 60A 12-48V Auto Support Parallel

MPPT Solar Charge Controller 60A 12-48V Auto Support Parallel Description

1、MAXIMUM 12 UNITS IN PARALLEL: The maximum number of 60A MPPT controllers that can be connected in parallel is 12 to increase the solar system total capacity and improve system overall power output. This can better meet the needs of large solar systems while improving the reliability and stability of the system. In addition, paralleling is also conducive to system maintenance and management, making the system operation more flexible and efficient 2、DUAL COOLING, EFFICIENT HEAT DISSIPATION: The 60 amp charge controller is constructed with die cast aluminum, ensuring excellent heat dissipation and reduced power consumption. Additionally, feature a silent intelligent bladeless fan for efficient cooling. The upgraded bladeless fan cooling system is quieter and more effective, suitable for use in RVs, commercial vehicles, boats, yachts, and solar systems 3、COMPATIBLE WITH MULTIPLE TYPE BATTERIES: Negative grounding design controller safer, 60A charge controller is compatible with a variety of 12, 24, 36, 48V batteries; Sealed, gel, flooded and lithium battery charging parameter pre set, other battery can be customized charging parameter according to your need. user programmable absorption voltage, float voltage, low voltage cutoff, load timer. real time energy logging. Recommended wire size is 9AWG 4、WIDE RANGE VOLTAGE OR POWE SUPPORT: 60A solar controller support high PV input power/voltage. The charger controller can accept solar voltage up to 160V. When battery is 12V system, suggest solar power 720W, suggest range from DC20V~DC80V; 1440W 37~105V when in 24V; 2100W 50~160V when in 36V; 2800W 72‑160V when in 48V 5、ECCICIENT TRACKING TECHNOLOGY: mppt charge controller with advanced Maximum Power Point Tracking technology can continuously tracking the array maximum power point to get the maximum power to charge the battery. The tracking efficiency is not less than 98. 1% and the peak conversion efficiency is up to 97%
Item Type: MPPT Solar Charge Controller
Model: HHJ60 PRO
Rated Charging Current: 60A
Size: Approx. 215 x 130 x 85mm / 8.46 x 5.12 x 3.35in
Charging Technology: MPPT
Charging Algorithm: 3 Stage
Charging Limited Current: 61A
Maximum Efficiency: 98.1%
PV Utilization Rate: 99%
Load Output: Rated Output Current: 6A
Maximum DC Output Current: 8A
Temperature Protection: 75/167
Fan Start Temperature: >45/104
Fan Stop Temperature:
