Multi-Channel 3A Buck Converter 3.3V/5V/12V Adjustable Power Supply Board
New
£13.72
Similar Products we think you'll like
Would you like us to let you know when it's back?
Description & Details
Summary
- Voltage Regulator: A power buck integrated circuit switch regulator, which can output 3A drive current, and enables excellent linearity and load regulation.
- Multi Channel Output: 4 groups of 3.3V, 5V, 12V and ADJ power supplies can be output at the same time. The module layout and wiring are in accordance with the power circuit design specifications.
- Better Design: Chip aluminum electrolytic capacitor and high power inductor are used to ensure stable output voltage. The window processing on the back of the PCB board is more conducive to the heat dissipation of the chip.
- Volt Adjusting Range: The ADJ output voltage of the module can usually be adjusted within the range of about 1V lower than the power supply voltage.
- The Using Tip: The module is a buck module, and the input voltage must be more than 1V and higher than the output voltage for stable output.
Multi-Channel 3A Buck Converter 3.3V/5V/12V Adjustable Power Supply Board Description
Buck Converter 3A Multi Channel 3.3V 5V 12V Adjustable Output Power Supply Board
Item Type: Buck Converter
Material: PCB
3.3V Output: Input 4.5-30V, output 3.3V ( 3%)
5V Output: Input 6.5-30V, output 5V ( 3%)
12V Output: Input 13.5-30V, output 12V ( 3%)
Adjustable Output: Input 4.5-30V, output 2V-28V adjustable.
Details
| OPC | PQRFT6D |
|---|---|
| Codes | 4991380987004 (EAN) |
