NEUTRIK - XLR Plug, 4 Pole, Black

NEUTRIK - XLR Plug, 4 Pole, Black Description

The NC4MXX-BAG from Neutrik is a 4 pole male XLR cable connector. This cable connector has Improved chuck type polyacetal (POM) strain relief provides higher pull-out force and makes assembly easier and faster, improved locking recess without window, more stringent housing increases durability and internal thread on shell is well protected against any damage. This is a sleek, valuable and handy connector with ergonomic design.

Boot with polyurethane gland gives high protection to cable bending stresses

Coloured rings and boots available for coding or identification

Latch lock device

Rugged zinc die-cast shell with black chromium plating for long lasting and dependable

Polyamide (PA 6.6 30 % GR) insert, brass (CuZn39Pb3) contact with silver plating

UL ECBT2.E135070 and cUL ECBT8.E135070 certified

Flammability rating meets UL 94 HB, IEC 61076-2-103 standard compliance, IP 40 protection class

Dielectric strength of 1.5KVDC, 10A rated current per contact and rated voltage < 50V

Lifetime > 1000 mating cycles, maximum wire size of 16AWG (1.5mm²)

Temperature range from -30C to +80C

Applications

Audio, Consumer Electronics

No. of Contacts: 4Contacts

Gender: Plug

Connector Mounting: Cable Mount

Contact Plating: Silver Plated Contacts

Connector Body Material: Metal Body

Product Range: XX
