OCDAY SP RACING F3 EVO Brush Flight Controller Control Through Indoor Coreless

OCDAY SP RACING F3 EVO Brush Flight Controller Control Through Indoor Coreless Description

Features:
1 F3_EVO_Brush revision is out of the F3 EVO SP RACING based on is based on a SP RACING F3 EVO firmware 32 brush flight control;
2 Improve the power supply input scheme, so that flight control support 1S (4.2V) and 2S (8.4V) power supply, 2S power can bring more violent flying experience. Individually designed circuit configuration, comes with Buck booster technology, or both 1S 2S power input, UART1 / 2/3 output 5V, DSM output 3.3V;
3 Using STM32F303CCT6 + MPU6500, advanced hardware platform F3 guarantee more stable flight;
4 With a large current NMOS transistors, operating current of up to 10A per channel or more. Each motor and is equipped with a freewheeling diode;
5 Support for PPM, SBUS, DSM receiver input signal;
6 With battery voltage detection and buzzer interface;
7 Support for the current world face almost all coreless motors, including the 1020 and other behemoths of the hollow cup.

Specification:
Item Name: SP RACING F3_EVO_Brush Flight Control
Material: Composite Material

Package Included:
1
