(Proxmark3 Set) Proxmark3 Develop Suit Kits V5.0 512M 3.0 Proxmark NFC PM3 RFID Reader

(Proxmark3 Set) Proxmark3 Develop Suit Kits V5.0 512M 3.0 Proxmark NFC PM3 RFID Reader Description

Features:

1. 2 Usb Ports: One Is Used For Mobile Power, The Other Can Be Monitored Offline

2. From At91sam7s256 To At91sam7s512

Compared With The Improvements Of Pm3 Rd V2.0:

1. Built-In High-Frequency Antenna, Corresponding To The Antenna Depth, Eliminates Blind Spots, And Reads The Entire Data Card Without Interruption.

2. Increase The Frequency Of Keystrokes, The Size Of The Card Can Hold Everything.

3. The Data Analysis Is Completely Stable And The Error Rate Is Low.

4. The Low-Frequency Antenna Improves The Signal-To-Noise Ratio, The Recognition Speed Is Higher, And The Mobile Design Meets Various Needs.

5. No Antenna Interface, No Need To Connect, Easy To Damage.

6. It Is Simple And Convenient To Cancel The Lithium Battery. (In Offline Mode, You Can Use The Power Bank)

7. Except That It Has Nothing To Do With The Original Relay, It Has Low Cost, Light Weight And Convenient Transportation.

Compatible With All Official Firmware, You Can Clean Up Any Version As Needed.

You Can Use The Official "Command Line" Or "Proxmark Tool.Exe" To Work According To Your Preferences

(The Low-Frequency Antenna Is Installed On The Right Side)

Antenna #Lf: 30.41 V @ 125.00 Khz

Antenna #Lf: 22.01 V @ 134.00 Khz

# Antenna High Frequency: 28.43 V @ 13.56 Mhz

(The Low-Frequency Antenna Is Installed On The Left Side)

Working Voltage: 3.5-5.5v

Working Current: 50-130ma

Length And Width: 54mm*86.6mm

Thickness: 6.2mm (The Thinnest) 9.8mm (With Screws) 15.8 (With Low Frequency Antenna)

Card Operation Method:

1. Ordinary Card Reader M1 S50 And Other Type B Cards 14443a.

2. Use Department-Specific Security Analysis Prng 0.

3. Use Built-In Security (Mfoc) To Parse The Entire Map.

Simulation Card Mode:

1. Mifare S50/Ultra-Light/Transparent Card Series That Simulates User Identification.

2. M1 S50 Simulation Data Of The Entire Sector. (Select A Card Reader)

3. Simulate The M1 S50 Protection Board To Obtain The Data Used To Calculate The Key (Select A Card Reader)

Silent Mode:

1. The Silent Data Transmission Analyzer Analysis Key Between The M1 S50 Card And The Card Reader.

2. Type B 14443a Silent Card Reader With Complete Communication Functions.

The Reader Is Used To Debug And Analyze Stocks.

Low Frequency:

Card Operation Method:

1. Read Low-Frequency Cards Such As Id, Hid, T55xx, Indala, Etc.

2. Use The T5577 Id / Hid / Indala Record Card To Convert It Into Three Cards.

Simulation Card Mode:

1. Enter Id/Hidden Card, Similar To The Specified Card Type.

2. Analog Modulation Scheme, Indicating Data Card And Ask/Fsk/Psk

Silent Mode:

1. Silently Sniff The Data Between The Card And The Reader (Less, Untested)

It Supports The Copying Of Most Cards, But Not All Of Them, And It Does Not Support Live And Special Card Reading And Writing.

Package Includes(Optional):

Type 1:

1*Proxmark3 Set

Type 2:

10*UID Buckles

Note:

Package does not include laptop, thank you!
