RAK12501 GNSS GPS Location Module L76K Compact GNSS Module with UART, Ideal for Low-Power Tracking

RAK12501 GNSS GPS Location Module L76K Compact GNSS Module with UART, Ideal for Low-Power Tracking Description

The RAK12501 GNSS Location Tracker Module uses the for Quectel L76K and is designed to be part of a production-ready IoT solution in a modular way. It must be combined with a WisBlock Core and a Base module to work as an LPWAN tracker device.
The RAK12501 supports a wide variety of satellite data protocols, such as GPS, GLONASS, QZSS, and BeiDou. The module features exceptional performance, high sensitivity, and minimal acquisition . A very suitable module for your low-power IoT solution needs. It works with standard protocols over UART connection to the MCU.
Track your assets, devices, or outdoor sensors with high-precision GNSS using the cost-effective RAK12501 module. It's built for Meshtastic GPS tracker projects and other LPWAN-based solutions, offering accurate location data without breaking the bank.

it's useful:
Built for budget-conscious tracking - Lower cost alternative for GNSS-enabled devices
Fast location updates - Starts tracking in under 15 seconds
Global satellite support - Works with GPS, GLONASS, BeiDou, Galileo, and QZSS
Compact and efficient - Small size, low power draw, and UART-only simplicity
Reliable performance - High sensitivity ensures strong signal even in environments

Key Features of RAK12501 GNSS Module:
Uses the GNSS Module: Quectel L76K
Supports 33 tracking channels, 99 acquisition channels, and 210 PRN channels
Log position information to internal flash memory
Supports GPS, GLONASS, Galileo, BDS and QZSS satellite systems
Serial communication to WisBlock Core support with NMEA 0183 protocol
High sensitivity, -165 dBm @ Tracking, -148 dBm @ Acquisition

1Hz update rate
Fast acquisition times:
Cold Start: < 15 s
Warm Start: < 5 s
Hot Start: < 1 s
Module Size: 10 mm x 23 mm
Color: Black
Materi
