RS232 Relay Module 1 Channel Opto 8 Bit MCU SP3232

RS232 Relay Module 1 Channel Opto 8 Bit MCU SP3232 Description

1、Functionality: A relay is an electrical control device, which causes the controlled quantity in the electrical output circuit to have a predetermined step change when the change in the input quantity (excitation amount) meets the specified requirement. 2、Interactive System: It has an interactive relationship between the control system (also known as the input circuit) and the controlled system (also known as the output circuit). 3、Automation Ready: Usually used in automated control circuits, it is essentially an automatic switch that uses a small current to control the operating of a large current. Therefore, it plays roles such as automatic adjustment, safety guard, and circuit conversion in the circuit. 4、8 Bit MCU: The RS232 relay module is designed with a stable 8 bit MCU, complemented by an RS232 level communicating chip, optimizing the performance and reliability of communicating and control systems. 5、1 Channel Relay Module: Using the standard RTU format of RS232 communicating protocol, it can realize 1 channel input signal detection and 1 channel relay output, which can be used in digital quantity detection or power control occasions.
Item Type: Relay Module
Material: PCB
Power Supply Voltage: 5-32V
Communicating Protocol: Supports Standard for Modbus RTU ProtocolCommunicating Interface: RS232 Interface
Communicating Baud Rate: 4800 9600 19200, Default 9600bps, Supports Power Off Memory
Output Signal: Relay Switch Signal
Device Address: Range 1-255, Default 255, Supports Power Off Memory
Product Size: Approx. 59x42mm / 2.3x1.7in
1 x Relay Module
