RTK-960 ZED-F9P BDS/GPS/GLONASS//QZSS RTK Positioning Module

RTK-960 ZED-F9P BDS/GPS/GLONASS//QZSS RTK Positioning Module Description

1. High precision, low power consumption and small size
2. Based on the latest generation NebulasIV baseband and high-precision algorithm integrated GNSS SoC chip
3. Support full-system multi-frequency point on-chip RTK positioning solution
4. Support BDS B1I/B2I/B3I+GPS L1/L2/L5+GLONASS L1/L2 + E1/E5b /E5a + QZSS L1/L2/L5+ SBAS
5. System-wide multi-frequency RTK engine and gypsophila RTK technology

WTRTK-960 is a of BDS/GPS/GLONASS//QZSS full-system multi-frequency and high- precision RTK positioning module, based on the design of a of baseband and high-precision algorithm integrated GNSS SoC chip-NebulaslV independently developed by hexinxingtong. It can simultaneously track BDS B1I/B2I/B3I//B2a *,GPS L1C/A /L2P/L5, GLONASS L1/L2, E1/E5b/ , QZSS L1/L2/L5 and other signal frequency points. It is oriented to high-precision navigation and positioning fields such as deformation monitoring, high-precision GIS, unmanned aerial vehicle, mower, precision agriculture, surveying and mapping, intelligent driving, etc.
tracking of satellite frequency points and 60dB narrowband anti-interference technology.
Advanced interference detection function.
Positioning accuracy: RTK positioning: horizontal 0.8cm + 1ppm, elevation 1.5cm + 1ppm.
Application:
1. vehicle positioning and navigation
2. mobile phones, tablets, handheld devices
3. embedded positioning equipment
4. wearable devices
5. unmanned aerial vehicles, precision agriculture, robots
Due to different product batches, the appearance may be different, which does not affect use.
Colour:Black
Material:PC+Metal

Package Contents:
1 * Positioning Module

Only the above package content, other products are not included.
Note: Light reflection and different displays may cause the color of the item in the picture a little different from the real thing. The measurement allowed error is +/- 1-3cm.
