Solenoid Relay Iron 48V 400A Continuous Duty

Solenoid Relay Iron 48V 400A Continuous Duty Description

Description: 200A Normally Open High Current Contactor Solenoid Relay for starting cars, heavy duty trucks, forklifts, etc. 36/48V Continuous Solenoid Relay adopts thick copper screw, which ensures the high current to pass smoothly Low power consumption design, shell uses improved material, solid, high temperature resistant, flame retardant Prevents the equipment from discharging the main battery when it is operated while the engine is off Max Transient current can be 400A, but Continuous Working Current recommend under 150 Amp Specification: Material: Iron Dimensions: Approx.70 X 64 x 60mm / 2.76 X 2.52 X 2.36 Inch Model: ZL180 Electric column diameter: 40mm / 1.57 Inch : Length: 64mm / 2.52 Inch Pole diameter: 8mm / 0.31 Inch column diameter: 5mm / 0.20 Contact load: 120A 14VDC Contact switching current: 120A Contact switching voltage: 36VDC 48VDC Contact form: 1H 1A Normally Current Rating: 120A Rated voltage: 36V, 48V Waterproof and dustproof : 220VAC Package Includes: 1 Piece High Current Contactor Relay Note: Please allow 0.5-1 Inch difference due to manual measurement.(1 Inch=25.4Mm) Please check the size measurement and the picture carefully before making payment. Due to the difference between different monitors, the picture may not reflect the actual color of the item. Please understand,
