Stepper Motor Controller 2-phase Stepper Motor Driver for 57 86 Series Motor

Stepper Motor Controller 2-phase Stepper Motor Driver for 57 86 Series Motor Description

Description:
Stepper Motor Controller 2-phase Digital Stepper Motor Driver 18-48 VDC Max. 4.2A for 57 86 Series Motor.

Specifications:
Product Name: DM542 Stepper Motor.
Power Supply: DC 24-60 (V).
Current Maximum: 4.5A.
Output Phase Current: 1.5A-4.5A.
Logic Input Current: 10-20mA.
Operating Temperature: -15+45.
Size: 11.7*8.5cm/4.61*3.35inch.
Quantity: 1 Pc x Stepper Motor.

Features:
- The driver integrates overvoltage and overcurrent protection.
- Input signal optical isolation.
- Dipolar constant current chopping method.
- DC power supply 20-50VDC (24-48VDC work is recommended).
- Maximum drive current 4.2A.
- The output current dial switch is adjustable.
- Low speedm zero vibration, and low noise.
- High subdivision:2,4,8,16,32,64,128,5,10,20,25,40,50,100,125.
- Strong anti-interference ability, high-precision positioning canbe achieved in the harsh encironment of the power grid.
- High reliability:power devices have enouth margin, and they have been strictly tested before leaving the factory.

Package Included:
1 Pc x DM542 Stepper Motor Driver
