Variable Frequency Drive 2.2KW Single Phase To 3 Phase VFD Mini Frequency Inverter AC 220V Input AC 0?220V Output

Variable Frequency Drive 2.2KW Single Phase To 3 Phase VFD Mini Frequency Inverter AC 220V Input AC 0?220V Output Description

Feature:
1. SINGLE TO 3 PHASE VFD: This frequency inverter single phase AC220V inputs and 3 phase AC 0? outputs, small in size but has large torsion and strong function.
2. COPPER CORE COIL: The VFD has enough excellent copper core coil, features strong resistance, superior performance and strong load capacity.
3. MULTI MODES: The converter can be controlled by VF, vector control and output torsion control, has 6 speed control modes, can run automatically.
4. OTHER FUNCTIONS: The controller is equipped with RS485 communication interface, speed potentiometer and external panel, built in synchronous control and proportional synchronous control.
5. GOOD HEAT DISSIPATION: The converter has strong cooling fan, built in aluminum block to assist heat dissipation, safer and more reliable.
6. WIDE RANGE OF APPLICATION: The motor controller adopts rail type installation, suitable for wind generator, water pump, automatic machine tool, engraving machine, etc.
Specification:
Item Type: Variable Frequency Drive
Material: PC, Aluminum
Adapter Motor: 2.2KW 3HP
Protection Class: IP20
Installation Height: Up to 1000 meters (3280 feet) above sea level, if the installation height is higher than this value, the current should be reduced by 1.2% for every 10 meters (328 feet) of height
Operating Ambient Temperature: 0¡ãC to 40¡ãC (32¡ãF to 104¡ãF)
Storage Temperature: -20¡ãC to 55¡æ (-4¡ãF to 131H)
Air Humidity: 5% to 85% during operation, no condensation or freezing; 5% to 95% during storage.
Package List:
1 x
Variable Frequency Drive1 x Manual
Note:
Pay attention to electricity safety when installing and using.
