Vector Network Analyzer 2.8Inch Display, 50 KHz900 MHz, Antenna Network Analyzer

Vector Network Analyzer 2.8Inch Display, 50 KHz900 MHz, Antenna Network Analyzer Description

PCB size and layout PCB dimensions: 54 mm x 85.5 mm x 11 mm (excluding connectors and switches) Frequency measurement Measuring range: 50 kHz to 300 MHz Extended firmware option: 50 kHz to 900 MHz available with extended firmware RF output and stability RF output level: 13 dBm (maximum 9 dBm) Frequency stability: < 0.5 ppm Why you need this Enables precise RF measurement during development and testing Provides a stable and repeatable RF output for reliable bench testing Compact size supports easy integration into custom hardware and prototypes What makes it stand out Wide frequency measurement range with optional firmware extension for higher coverage Clear, fixed RF output specification supports predictable performance in experiments and in product development Small PCB footprint reduces enclosure and integration complexity Use scenarios and applications Prototyping wireless sensors and Internet of Things devices Use for calibrating, validating, and debugging RF links early in the design cycle Lab calibration and signal verification Provides a dependable reference for testing RF components, modules, and boards RF module development and embedded systems testing Useful for developing and validating wireless communication subsystems with consistent output and measurable accuracy Compatibility and integration notes Designed as a measurement and RF output module for development projects Excludes connectors and switches, allowing flexible integration with existing hardware and custom boards Key attributes at a glance Function: RF measurement and RF output module for development and testing Compatibility: Suitable for integration into RF development workflows and embedded projects (firmwareextended range option) Size: 54 x 85.5 x 11 mm (excluding connectors and switches) Material: not specified Performance: measuring range 50 kHz to 300 MHz, extendable to 50 kHz to 900 MHz with extended firmware, RF output 13 dBm (max 9 dBm), stability < 0.5 ppm
