Wall Panel HDMI KVM Switch, A Port USB with Remote Control

Wall Panel HDMI KVM Switch, A Port USB with Remote Control Description

Specifications
StandardsHDMI 1.4HDCP 1.4;
Maximum pixel clock: 340MHz;
Maximum data rate: 10Gbps;
Resolution range Up to 4Kx2K@30Hz, 3D, 1920*1080@60Hz;
ConnectorHDMI-A Interface;
HDMI-A Interface: <5M( Resolution: 1920*1080@60Hz);
Interface protocols: USB2.0;
PC input interface typeUSB-B;
Output interface type: Output interface type;
Power supplyUSB Power;
Power dissipationMAX 2W;
TemperatureOperating: -5 ~ +70;
HumidityOperating: 5% ~ 90%;
Dimension100*60*20mm;
Features:
*The 2 routes of high-definition video source and USB interface implementation freely switch;
*Support video resolution up to 3840*2160 @30Hz
*Compliance with HDMI 1.4 standard; >.Adaptive EDID/HDCP decryption, able to adapt to a variety of complex application environment;
*Switched by button, which is convenient and quick; >.Support USB device, such as HUB, U-disk, printer, etc. >.HDCP 1.4 standard - high-bandwidth digital content protection technology;
*High compatibility, can auto-match source and display device; >.Built-in automatic adjustment system, make the image smooth, clear and stable;
*Built-in ESD protection system;
*Simple to install, plug and play;

Description:
HDMI 2 ports KVM switch; 2 groups of high-definitionvideo source and USB interface realize freely switch.
Adaptive EDID/HDCP decryption. The equipment has excellent image processing and transmission capacity,make the output signal is more smoother and stable,is a reliable, high performance and efficient way ofHDMI
USB switch. Suitable for office, computer room, monitoring host, etc.

Package Included:
1 Pcs HDMI KVM2*1 Switcher
2 Pcs USB Cable
1 Pcs User Manual
