4 Way Full Protocol Desktop Charger Multi-Function

4 Way Full Protocol Desktop Charger Multi-Function Description

Three input interfaces are supported:Various power supply methods:Support xt60, dc5.5mm.type-c three input interfaces. If you use type-c power supply, the power supply equipment needs to support 20v and output capability above 5a.1. It is recommended to use the fast charge C port input within 100w, and the power supply equipment needs to support the output capacity of 20v5a or more. 2.100w recommended to use dc input. 3. It is recommended to use xt60 input for 100-400w
Built-in suction cooling fan, 1.5-inch IPS display see-through charging process, The can display the output real-time data of each channel.
Main interface, It can also display the current and voltage curve parameters of each channel separately,Display rich, data at any time, Real-time voltage of each port, Real-time current of each port, Real-time power of each port, Real-time power of each port
400W full protocol desktop charger, 4-way 3518s step-down design, The fast charging agreement basically covers, All types of electronic products on the market,Three kinds of input interfaces, high conversion efficiency, low calorific value, IPS display, supports almost all mainstream protocols, fast charging does not damage the machine, supports firmware upgrades
4 way SW3518S, buck design, Input 24v can output 5-20v voltage, and each channel supports up to 20v5a fast charge output.The product has low no-load heat generation and high conversion efficiency.

Craftsmanship
Protect equipment with "high-quality chips"
The main control part adopts AT32F415CBT7 single-chip microcomputer, which has the characteristics of stable high-frequency performance, fast display interface refresh rate, and not crash for a long time.
In the later stage of the firmware part, you can use the type-c data cable to directly connect to the computer for upgrading.
Multipleprotections actively filter dangers
temperature protection
Short circuit protection
Input Overvoltage Protection
Input overcurrent protection
Output overcurrent protection
Output Overvoltage Protection
Fast and stable charging
Can be at the same time
Steps to upgrade the firmware of the road fast charging module:
1. Prepare an A2C data cable and connect one end to the computer;
2. Disconnect the external power supply of the charger and that the charger is turned off;
3. In the off state, and hold this button, and insert the other end of the usb cable into the "USB" interface on the rear of the charger;
4. At this time, a 100M mobile hard disk be virtualized on the computer side. Copy the ".bin" format firmware file to this mobile hard disk, and the device automatically upgrade, and it automatically restart after the upgrade is successful.
Colour:Black
Material:plastic+metal

Package Contents:
1 x Fast Charging Module

Only the above package content, other products are not included.
Note: Light reflection and different displays may cause the color of the item in the picture a little different from the real thing. The measurement allowed error is +/- 1-3cm.
