500hz-50khz Handheld Inductance Capacitance Meter Inductance Capacitance Multimeter for Technical Engineering

500hz-50khz Handheld Inductance Capacitance Meter Inductance Capacitance Multimeter for Technical Engineering Description

Feature: 1. Come with clear correction function, capacitance mode for open circuit correction, inductance mode for short circuit correction 2. Possess frequency display function: While measuring the component under test, you can view the current measurement frequency 3. Widely used in scientific research and technical engineering, factory electronic instrument testing, electronic instrument maintenance, school laboratory teaching, electronic designs, etc. 4. Online calibration, no loss of parameters when power‑off, no fear of sudden power‑off, online calibration at any time, measurement is more accurate and convenient 5. The LC‑200A type multifunctional inductance and capacitance measuring instrument has four measuring positions, which is easy to use Specification: Item Type: Inductance Capacitance Meter Material: ABS Model: LC-200A Level Position: C level capacitance level (1pF-10μF) L level inductance level (1μH-100mH) Hi.L large inductance level (100mH-100H) Hi.C level large capacitance level (1μF-100mF) Test Frequency: L Level, C Level: 500KHz Hi.C Level: 500Hz-50KHz Inductance Capacitance and Large Inductance Measurement Method: LC resonance Large Capacitance Measurement Method: Charge and discharge Display Mode: 1602 LCD screen Effective Display Digits: 4 Power Supply Interface: Mini USB and Φ5.5DC socket, 4 x AA batteries(not include) Voltage: 5V Size: Approx. 150 x 89 x 29mm / 5.9 x 3.5 x 1.1in Package List: 1 x Inductance Capacitance Meter 1 x QR Code User Manual 1 x Data Line 2 x Crocodile Clip Come with clear correction function, capacitance mode for open circuit correction, inductance mode for short circuit correction Possess frequency display function: While measuring the component under test, you can view the current measurement frequency Widely used in scientific research and technical engineering, factory electronic instrument testing, electronic instrument maintenance, school laboratory teaching, electronic designs, etc. Online calibration, no loss of parameters when power‑off, no fear of sudden power‑off, online calibration at any time, measurement is more accurate and convenient The LC‑200A type multifunctional inductance and capacitance measuring instrument has four measuring positions, which is easy to use
