5pcs DC 3.6-6V Bluetooth 2.0/3.0 Module SPP Protocol Android Compatible with HC-05/06

5pcs DC 3.6-6V Bluetooth 2.0/3.0 Module SPP Protocol Android Compatible with HC-05/06 Description

Product introduction:
Bluetooth is based on Bluetooth 3.0 SPP design, which can support Windows, Linux, android data transmission, working frequency 2.4GHZ, modulation mode GFSK, maximum transmission power 8db, maximum transmission distance 30 meters, support users to modify device name through AT command The baud rate and other instructions are convenient and quick to use.

Applications:
The product is a classic Bluetooth protocol that can communicate with Bluetooth-enabled computers (desktops, notebooks) and mobile phones (android). Can be applied.
Windows computer Bluetooth serial port transparent transmission.
Android Bluetooth serial port transparent transmission.
Smart home control.
Automotive ODB testing equipment.
Bluetooth toy.
Share mobile power, share weight.
Medical equipment.

Specification:
Working frequency: 2.4GHZ.
Communication Interface: UART.
Operating Voltage: SMD type: 1.8-3.6V (3.3V recommended) with backplane: 3.6-6V (recommended 5V).
Operating temperature: -40 C - 80 C.
Antenna: Built-in PCB antenna.
Transmission distance: 30 meters.
ma-ster-slave support: Slave.
Module size: 19.6 * 14.94 *1.8 mm (length, width, height).
Bluetooth version: Bluetooth 3.0 SPP.
STM soldering temperature: <260C.
Unconnected operating current: 4.7mA.
Current after BLE connection: 7.3mA.
Transmit power: 8db (maximum).
Receiving sensitivity: -97dbm.
SPP maximum throughput: 16K bytes/s (android, windows).

Package includes:
5 x Module
